Smallest, Small, Middle, Big, Biggest Soft Gelatin Capsule Filling
Machine For Fish Oil Capsules
Backgroud
A Soft Capsule is a Capsule preparation that is formed by
encapsulating an oily drug, a drug solution, or a drug suspension
with a Capsule shell made of gelatin (or other supplementary
materials) , most commonly used in drugs or dietary supplement, the
common methods of preparation include dropping method and pressing
method
Soft capsule production is applyed by softgel encapsulation method,
which is the preferred process, this article only about the
encapsulation method)
The basic principle of the softgel encapsulation method is that the
rubber sheet passes through a pair of cylindrical moulds, and the
feeding pump injects a fixed amount of liquid medicine into the
rubber sheet through the spray body, form a completely closed
capsule.
Below we will introduct our soft gelatin capsule filling machine.
You will know basic information for it. Let’s start now.
Introduction for soft gelatin machine
Based on more than 15 years experience on softgel machine equipment
production, we can supply high quality soft gelatin capsules
filling machine, from R&D machine to big machine; from
Half-automatic machine to full-automatic machine; From mechanical
gear machine to servo motor machine. Soft gelatin capsules filling
machine is one kind of pharmaceutical and food machine, which has a
wide range of application. You can find it in medicine industry,
chinese traditional medicine, candy industry, child medicine
industry, animal medicine industry, health care industry, skin care
industry, tobacco industry.........
Different model machine
| Technical Specification | JLH-250III | JL-250II | JL-150III | JL-100II |
| Output | 88200/h(20#OB; 6rpm) | 58800/h(20#OB; 4rpm) | 17280/h(20#OB; 3rpm) | 8640/h(20#OB; 4rpm) |
| Die Roll Size | Φ150×250mm | Φ150×250mm | Φ150×100mm | Φ80×100mm |
| Die Roll Speed | 0-7rpm | 0-5rpm | 0-4rpm | 0~5rpm |
| Feeding Range | 0-2mL | 0-2mL | 0-2mL | 0-2mL |
| Feeding Variance | ±1.5% | ±1.5% | ±1.5% | ±1.5% |
| Overall Size | 2200*1000*1900 | 2040*960*1900 | 1800*900*1750 | 1440×660×1350 |
| Overall Weight | 1800Kg | 1500Kg | 650Kg | 400 Kg |
| Total Power | 12kw | 10kw | 6kw | 5kw |
| Electrical Power | 380V/220V/480V/110V/240V/208V/400V/415V 50HZ/60HZ 3Phase |
Advanced technology and Feature show
- All bearings used on the machine are imported bearings(decrease
equipment wear rate, so that the working life can be improved)
- All the gears and main axis used inside this softgel machine adopt
CrWMn and tin-bronze and 40cr high
frequency quenching. The
hardness can be as high as HRC50-55(durable in use)
- The net gelatin pulling axises can be adjusted in valuable
frequency and there is special coating on it.
- The speed of the gelatin film rollers can be adjusted separately
and can be adjusted in valuable
frequency
During production, if
the quality of the liquid gelatin is not good, we can solve the
problem by adjusting the speed of the gelatin film rollers.
- The feeding hopper of the sofgel machine can be heated and kept
warm. You can choose electric heating or water circling heating
style. And special medicine automatic supplying design makes
operating easier
- We adopted big cam for the injecting pump, so this softgel machine
is very suitable for viscous herbal filling material.
- Lock mode of softgel machine die rollers(three-point lock)
By using three-point lock mode, the alignment of the die rollers
will never change after locked. And at the same time, the alignment
can be fine-turned, very easy to operate.
What you may want to know?
Price for those good machine?
It is only one third of Korea machine.
Warranty time?
12 months after installed at your side.
Delivery time?
60 days or less (we made one 30 days urgently before)
Training?
It can be at our factory site or at your factory site.
FAT?
No problem if need.
